3-24 Service Guide N5230-90014
Tests and Adjustments PNA Series Microwave Network Analyzers
System Verification N5230A
4. In the Calibration Kit box, select the calibration kit or electronic calibration module
(ECal) that is being used by clicking on it. The corresponding verification kit to use is
selected for you and displayed in the Verification Kit box. Refer to Figure 3-9.
5. Under Printer Output, click one of the following options. Refer to Figure 3-9.
• Print Tabular Data: Prints the verification data in tabular form which includes
measured data and uncertainty limits. For an example, refer to Figure 3-11 on
page 3-26.
• Print Graphs: Prints the verification data in graphical form. The graphical form
includes the measured data trace, factory supplied data trace, and uncertainty
limits. For an example, refer to Figure 3-12 on page 3-27.
• File Tabular Data: Writes the tabular data to a text file in the C:\Program
Files\Agilent\Network Analyzer\Documents\ directory.
• File Graphs: Saves a screen image in PNG format in the C:\Program
Files\Agilent\Network Analyzer\Documents\ directory.
NOTE
For printed output, it is assumed that the printer has been tested and the
Windows driver is installed for the printer that is being used. The system
verification test prints to the printer that has been designated as the default
printer. (On the Windows Desktop display, click on My Computer, Control
Panel, and then Printers to verify the printer setup.)
To modify the number of ports to be verified or to change the number of devices to
measure, click on the Configure tab and make the desired selections.
6. Click Run.
7. Follow the instructions on the analyzer for performing a full calibration or recalling an
existing recent calibration.
8. Follow the instructions on the analyzer for performing the system verification, inserting
the verification devices as prompted.
