Agilent Technologies N5230A User Manual

Service Guide N5230-90014 4-17
PNA Series Microwave Network Analyzers Troubleshooting
N5230A Front Panel Troubleshooting
Checking the Front Panel Keys
To check the front panel keys, push each key and compare the decimal value in the Value
box under Keys to the key values in Table 4-5.
• If all the key values are correct, then the A1 front panel keypad is working. If some of
the keys are not working, suspect a faulty A1 keypad. To replace the A1 keypad, refer to
“Removing the A1 Keypad Assembly” on page 7-10.
• If none of the keys are working correctly, suspect a faulty A3 front panel interface
board. To replace the A3 front panel interface board, refer to “Removing the A3 Front
Panel Interface Board” on page 7-10.
Table 4-5 Keyboard Key Numbers
Key
Value
Front
Panel Key
Key
Value
Front
Panel Key
Key
Value
Front
Panel Key
Key
Value
Front
Panel Key
50
Tab
←
66
Measure
Setups
82 7 98 1
51
Up
↑
67 F2 83 8 99 2
52
Tab
→
68 F3 84 6 100
+/−
⇐
53 Window 69 F4 85 M/u 101
Not
Applicable
54 OK 70 Help 86 Cancel 102
Not
Applicable
55
Start/
Center
71 Trigger 87 Marker 103 Save
56
Stop/
Span
72 Average 88
Marker
Table
104
Maximum
Window Icon
57 Power 73 Calibrate 89
Limit
Table
105 Preset
58
Down
↓
74 F1 90 4 106 0
59 Click 75
Not
Applicable
91 5 107 .
60 Trace 76 9 92 3 108
Not
Applicable
61
Display
Configure
Icon
77 G/n 93 Enter 109
Not
Applicable
62
Not
Applicable
78
Menu
Dialog
94
Not
Applicable
110
Not
Applicable
63
Sweep
Setup
79 Measure 95
Marker
Search
111 Recall
64 Channel 80 Format 96
Marker
Function
112
Print
Icon
65
Sweep
Type
81 Scale 97
Math/
Memory
113 Macro
