AGTRON Legend - Figure 4-11 Installation Diagram

MND172201 P a g e | 15 Software Revision 1.4.1
Figure 4-11 Installation Diagram
Part Number
Description
AGD1710
The Legend S.A. Wi-Fi ECU
050013005
Antenna 2.4 GHZ 7”
AGD2006
Battery Harness 22ft (6.7m)
AGD1733
Legend S.A. Wi-Fi Power Harness
AGD1719
Legend S.A. Loop Harness
AGD1725
Legend S.A. Air Cart Harness
4TYWR14.0
850040001
850040002
Black Cable Ties (14.5”)
Blue Cable Ties (4”)
Yellow Cable Ties (4”)
MNST082
Manual
Optional Parts
Part Number
Description
050010001
30 amp Fuse
AGWL170
Android Tablet 8” Wi-Fi/GPS
AGD2020
Power Extension Harness 35ft (10.7m)
AGD2031
Power Extension Harness 15ft (4.5m)
050013007
Magnetic Antenna Base
Diagram is not to scale
Figure 4-11
