AIREDALE EasiCool - Df35 Wx - Df45 Wx

EasiCool™ Precision Air Conditioning
DF35WX-EZRE-0 DF40WX-EZRE-0 DF45WX-EZRE-0
Capacity
Nom Cooling (Gross) (1) kW
34.5 38.5 43.2
Total Heat of Rejection (1) kW
46.0 51.2 57.4
Capacity Steps
1 1 1
Fan Power Input (Fan Gain) (2) kW
4.60 6.30 6.30
Dimensions - W x D x H mm
1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940
Weight - Machine / Operating (3) kg
537 / 543 565 / 571 640 / 650
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1 1/1 1/1
Condenser
Stainless Steel Brazed Plate
Water Volume l
6.1 6.1 9.9
Evaporator Fan Motor - AC Motor
Centrifugal Forward CurvedAC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1 1 1
Motor Shaft Power (4) kW
4.00 5.50 5.50
Speed @ 25Pa / Maximum ESP rpm
980 /1078 1094 / 1186 1094 / 1186
Maximum ESP Pa
165 175 175
Nominal Airow m³/s
3.30 3.70 3.70
Compressor - Scroll
Single
Quantity
1 1 1
Oil Charge Volume (Total) l
3.30 3.30 6.70
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total) (5) kg
6.0 6.0 8.7
Connections
Water Inlet / Outlet mm
35 35 42
Condensate Drain Hose mm
19 19 19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
3 3 3
OPTIONAL EXTRAS
Electric Heating (Total) kW
20.0 20.0 20.0
Humidier
Capacity kg/hr
3.0 - 15.0 3.0 - 15.0 3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head m
10.8 10.8 10.8
Flow l/m
5 5 5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1 N/A N/A
Motor Shaft Power (4) kW
5.50 N/A N/A
Speed @ Maximum ESP rpm
1196 N/A N/A
Maximum ESP Pa
322 N/A N/A
Fan Power Input (Fan Gain) (2) kW
6.30 N/A N/A
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2 2 2
Motor Shaft Power (4) kW
N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm
1895 / 2165 2135 / 2165 2135 / 2165
Maximum ESP Pa
285 70 70
Fan Power Input (Fan Gain) (2) rpm
5.26 5.26 5.26
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross (7) kW
30.0 31.5 31.5
Water Flow (Nominal) l/s
0.67 0.70 0.70
LPHW Connection Sizes mm
22 22 22
Threaded Connection
Brass Male Taper in
1 1/4 1 1/4 1 1/2
112
EasiCool Technical Manual 7525389 V1.8.0_05_2016
TechnicalDF
WX - Type
Technical Data Downow Units WX Type
Mechanical Data
DF35WX - DF45WX
