AIREDALE EasiCool - Airflow Components

EasiCool™Precision Air Conditioning
System Conguration
Downow Upow
X Type WX Type X Type WX Type
EC Fans 6 - 26
● ● ● ●
Airow Components
AC Fans 6 - 26
○ ○ ○ ○
AC Fans 28 - 60
● ● ● ●
EC Fans 28 - 60
○ ○ ○ ○
AC Larger Fan Motor**
○ ○ ○ ○
2 way Discharge Grille
– – ○ ○
3 Way Discharge Grille
– – ○ ○
Return Air Grille
– – ● ●
G4 Return Door Air Filter
○ ○ ○ ○
●
Standard Feature ○ Optional Feature – Not Available
** Model Dependant on selected units with AC fans as standard.
Airow Components
EC Direct Drive Forward
Curve Fan
EC Direct Drive Backward
Curve Fan
Pleated Disposable Panel Filter
15
EasiCool Technical Manual 7525389 V1.8.0_05_2016
