AIREDALE EasiCool - V50 Wx2 - V60 Wx2

EasiCool™ Precision Air Conditioning
V50WX2 - V60WX2Technical Data Upow Units WX Type
Mechanical Data
V50WX2-EZRE-0 V55WX2-EZRE-0 V60WX2-EZRE-0
Capacity
Nom Cooling (Gross) (1) kW
50.9 57.4 64.7
Total Heat of Rejection (1) kW
68.5 77.3 87.4
Capacity Steps
2 2 2
Fan Power Input (Fan Gain) (2) kW
7.0 7.0 7.0
Dimensions - W x D x H mm
2170 x 750 x 1940 2170 x 750 x 1940 2170 x 750 x 1940
Weight - Machine / Operating (3) kg
709 / 719 729 / 739 733 / 743
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
2/1 2/1 2/1
Condenser
Stainless Steel Brazed Plate
Water Volume l
9.9 9.9 9.9
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
2 2 2
Motor Shaft Power (4) kW
3 3 3
Speed @ 25Pa / Maximum ESP rpm
1243 / 1447 1243 / 1447 1278 / 1324
Maximum ESP Pa
255.00 255.00 35.00
Nominal Airow m³/s
4.2 4.2 4.6
Compressor - Scroll
Tandem
Quantity
2 2 2
Oil Charge Volume (Total) l
6.6 6.6 6.6
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total) (5) kg
8.9 9.7 9.8
Connections
Water Inlet / Outlet mm
42 42 42
Condensate Drain Hose mm
19 19 19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
5 5 5
OPTIONAL EXTRAS
Electric Heating (Total) kW
30.0 30.0 30.0
Humidier
Capacity kg/hr
3.0 - 15.0 3.0 - 15.0 3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head m
10.8 10.8 10.8
Flow l/m
5 5 5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
2 2 2
Motor Shaft Power (4) kW
4 4 4
Speed @ Maximum ESP rpm
1495 1495 1499
Maximum ESP Pa
305 305 230
Fan Power Input (Fan Gain) (2) kW
9.2 9.2 9.2
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2 2 2
Motor Shaft Power (4) kW
N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm
1370 / 1510 1370 / 1510 1510 / 1510
Maximum ESP Pa
165 165 25
Fan Power Input (Fan Gain) (2) kW
4.2 4..18 4.2
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross (7) kW
37.7 37.7 39.2
Water Flow (Nominal) l/s
0.84 0.84 0.87
LPHW Connection Sizes mm
22 22 22
Threaded Connection
Brass Male Taper in
1 1/2 1 1/2 1 1/2
132
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical
WX - Type V
