AIREDALE EasiCool - Df50 Wx2 - Df60 Wx2

EasiCool™ Precision Air Conditioning
Technical Data Downow Units WX Type
Mechanical Data
114
EasiCool Technical Manual 7525389 V1.8.0_05_2016
TechnicalDF
WX - Type
DF50WX2 - DF60WX2
DF50WX2-EZRE-0 DF55WX2-EZRE-0 DF60WX2-EZRE-0
Capacity
Nom Cooling (Gross) (1) kW
50.2 56.6 63.8
Total Heat of Rejection (1) kW
67.8 76.5 86.5
Capacity Steps
2 2 2
Fan Power Input (Fan Gain) (2) kW
5.20 5.20 7.00
Dimensions - W x D x H mm
2170 x 750 x 1940 2170 x 750 x 1940 2170 x 750 x 1940
Weight - Machine / Operating (3) kg
712 / 722 731 / 741 731 / 741
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
2/1 2/1 2/1
Condenser
Stainless Steel Brazed Plate
Water Volume l
9.9 9.9 9.9
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
2 2 2
Motor Shaft Power (4) kW
2.20 2.20 3
Speed @ 25Pa / Maximum ESP rpm
1167 / 1170 1167 / 1170 1307 / 1311
Maximum ESP Pa
35 35 75.00
Nominal Airow m³/s
4.20 4.20 4.6
Compressor - Scroll
Tandem
Quantity
2 2 2.00
Oil Charge Volume (Total) l
6.60 6.60 6.6
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total) (5) kg
9.0 9.7 9.8
Connections
Water Inlet / Outlet mm
42 42 42
Condensate Drain Hose mm
19 19 19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
4 4 4
OPTIONAL EXTRAS
Electric Heating (Total) kW
30.0 30.0 30.0
Humidier
Capacity kg/hr
3.0 - 15.0 3.0 - 15.0 3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head m
10.8 10.8 10.8
Flow l/m
5 5 5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
2 2 2
Motor Shaft Power (4) kW
3.0 / 4.0 3.0 / 4.0 4
Speed @ Maximum ESP rpm
1448 / 1498 1448 / 1498 1497
Maximum ESP Pa
310 / 360 310 / 360 275
Fan Power Input (Fan Gain) (2) kW
7.0 / 9.2 7.0 / 9.2 9.2
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2 2 2
Motor Shaft Power (4) kW
3.10 3.10 3.1
Speed @ 25Pa / Maximum ESP rpm
1265 / 1510 1265 / 1510 1390 / 1510
Maximum ESP Pa
320 320 185
Fan Power Input (Fan Gain) (2) kW
3.78 3.78 4.92
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross (7) kW
38.30 38.30 39.8
Water Flow (Nominal) l/s
0.85 0.85 0.89
LPHW Connection Sizes mm
22 22 22
Threaded Connection
Brass Male Taper in
1 1/2 1 1/2 1 1/2
