AIREDALE EasiCool - Df13 X - Df17 X

EasiCool™ Precision Air Conditioning
DF13X - DF17X
68
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical
X-Type DF
Technical Data Downow Units X Type
Mechanical Data
DF13X-EZRE-0 DF15X-EZRE-0 DF17X-EZRE-0
Standard Condenser Match
1 x CR22 1 x CR22 1 x CR30
Capacity
Nom Cooling (Gross) (1) kW
13.9 15.6 18
Capacity Steps
1 1 1
Fan Power Input (Fan Gain) (2) kW
0.62 0.67 1.04
Dimensions - W x D x H mm
990 x 670 x 1940 990 x 670 x 1940 990 x 670 x 1940
Weight - Machine (3) kg
241 241 242
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1 1/1 1/1
Evaporator Fan Motor - EC Motor
Centrifugal Forward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1 1 1
Motor Shaft Power (4) kW
N/A N/A N/A
Maximum ESP Pa
443 324 245
Nominal Airow m³/s
1.00 1.20 1.40
Compressor - Scroll
Single
Quantity
1 1 1
Oil Charge Volume (Total) l
1.20 1.66 1.89
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge (5)
Inert Gas
Connections
Liquid (Sweat) in
3/8 3/8 3/8
Discharge (Sweat) in
5/8 5/8 5/8
Condensate Drain Hose mm
19 19 19
Filtration
Disposable to BS EN 779 - G4 - 50mm
Quantity
2 2 2
OPTIONAL EXTRAS
Larger Condenser Match
CR30 CR30 CR50
Nom Cooling (Gross) (1) kW
14.1 16.0 18.3
Hot Gas Reheat
Nom Heating (Gross) (6) kW
7.4 8.1 8.6
Electric Heating (Total) kW
7.5 7.5 7.5
Humidier
Capacity kg/hr
0.6 - 3.0 0.6 - 3.0 0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head m
8 8 8
Flow l/m
5 5 5
Drain
10mm Stainless Steel Stub Connection
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1 1 1
Motor Shaft Power (4) kW
N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm
1105 / 1560 1310 / 1560 1515 / 1560
Maximum ESP Pa
310 195 45
Fan Power Input (Fan Gain) (2) kW
0.60 0.60 0.60
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross (7) kW
11.5 12.5 13.3
Water Flow (Nominal) l/s
0.26 0.28 0.30
LPHW Connection Sizes mm
22 22 22
Mechanical
(1) Entering air 24°C/45% RH ambient 35°C.
(2)
Fan Gain / Fan power input based upon fan operating with design airow at 25Pa ESP, these values may change with different ESP.
(3) With Standard forward curved fan motors; Machine weight includes a refrigerant charge.
(4) Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5) For refrigerant charges, refer to Unit Refrigerant Charge (kg/Circuit).
(6) Based on air temperature of 15.5°C leaving the evaporator coil.
(7) Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to Low Pressure Hot Water.
