AIREDALE EasiCool - V35 Wx - V45 Wx

EasiCool™ Precision Air Conditioning
V35WX - V45WXTechnical Data Upow Units WX Type
Mechanical Data
V35WX-EZRE-0 V35WX2-EZRE-0 V40WX-EZRE-0 V40WX2-EZRE-0 V45WX2-EZRE-0
Capacity
Nom Cooling (Gross) (1) kW
35.0 34.2 39 39.7 43
Total Heat of Rejection (1) kW
46.5 45.5 51.8 52.9 57.1
Capacity Steps
1 2 1 2 2
Fan Power Input (Fan Gain) (2) kW
4.60 4.60 6.30 6.30 6.30
Dimensions - W x D x H mm
1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940
Weight - Machine / Operating (3) kg
534 / 540 576 / 582 562 / 568 589 / 595 620 / 630
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1 2/1 1/1 2/1 2/1
Condenser
Stainless Steel Brazed Plate
Water Volume l
6.1 6.1 6.1 6.1 9.9
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1 1 1 1 1
Motor Shaft Power (4) kW
4.00 4.00 5.5 5.5 5.5
Speed @ 25Pa / Maximum ESP rpm
1440 / 1468 1440 / 1468 1620 / 1622 1620 / 1622 1620 / 1622
Maximum ESP Pa
35 35 25.00 25.00 25.00
Nominal Airow m³/s
3.30 3.30 3.7 3.7 3.7
Compressor - Scroll
Single Tandem Single Tandem Tandem
Quantity
1 2 1 2 2
Oil Charge Volume (Total) l
3.30 3.32 3.3 3.78 3.44
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type (5)
Thermostatic Expansion Valve (Optional EEV) / R410A
Charge (Total) kg
6.0 5.9 6 6.1 8.7
Connections
Water Inlet / Outlet mm
35 35 35 35 42
Condensate Drain Hose mm
19 19 19 19 19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
4 4 4 4 4
OPTIONAL EXTRAS
Electric Heating (Total) kW
30.0 30.0 30.0 30.0 30.0
Humidier
Capacity kg/hr
3.0 - 15.0 3.0 - 15.0 3.0 - 15.0 3.0 - 15.0 3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head m
10.8 10.8 10.8 10.8 10.8
Flow l/m
5 5 5 5 5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
Motor Shaft Power (4) kW
6 6 N/A N/A N/A
Speed @ Maximum ESP rpm
1695 1695 N/A N/A N/A
Maximum ESP Pa
240 240 N/A N/A N/A
Fan Power Input (Fan Gain) (2) kW
6.30 6.30 N/A N/A N/A
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2 2 2 2 2
Motor Shaft Power (4) kW
N/A N/A N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm
1935 / 2165 1935 / 2165 2165 / 2165 2165 / 2165 2165 / 2165
Maximum ESP Pa
260 260 25 25 25
Fan Power Input (Fan Gain) (2) kW
3.08 3.08 4.24 4.24 4.24
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross (7) kW
29.90 29.90 31.5 31.5 31.5
Water Flow (Nominal) l/s
0.67 0.67 0.70 0.70 0.70
LPHW Connection Sizes mm
22 22 22 22 22
Threaded Connection
Brass Male Taper in
1 1/4 1 1/4 1 1/4 1 1/4 1 1/4
130
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical
WX - Type V
