AIREDALE EasiCool - V35 X - V45 X2

EasiCool™ Precision Air Conditioning
94
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical
X-Type V
V35X - V45X2Technical Data Upow Units X Type
Mechanical Data
V35X-EZRE-0 V35X2-EZRE-0 V40X-EZRE-0 V40X2-EZRE-0 V45X2-EZRE-0
Standard Condenser Match
1 x CR50 1 x CR50 1 x CR65 1 x CR65 1 x CR80
Capacity
Nom Cooling (Gross) (1) kW
34.2 33.2 38.7 39.3 43.0
Capacity Steps
1 2 1 2 2
Fan Power Input (Fan Gain) (2) kW
4.60 4.60 6.30 6.30 6.30
Dimensions - W x D x H mm
1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940 1835 x 750 x 1940
Weight - Machine (3) kg
474 516 497 525 531
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1 2/1 1/1 2/1 2/1
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1 1 1 1 1
Motor Shaft Power (4) kW
4.00 4.00 4.00 4.00 5.50
Speed @ 25Pa / Maximum ESP rpm
1440 / 1468 1440 / 1468 1620 / 1622 1620 / 1622 1620 / 1622
Maximum ESP Pa
35 35 25 25 25
Nominal Airow m³/s
3.30 3.30 3.70 3.70 3.70
Compressor - Scroll
Single Tandem Single Tandem Tandem
Quantity
1 2 1 2 2
Oil Charge Volume (Total) l
3.30 3.32 3.30 3.78 3.44
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge (5)
Inert Gas
Connections
Liquid (Sweat) in
1/2 1/2 5/8 5/8 5/8
Discharge (Sweat) in
7/8 7/8 1 1/8 7/8 7/8
Condensate Drain Hose mm
19 19 19 19 19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
4 4 4 4 4
OPTIONAL EXTRAS
Larger Condenser Match
CR65 CR65 CR80 CR80 CR105
Nom Cooling (Gross) (1) kW
35.0 34.2 39.0 39.7 43.0
Hot Gas Reheat
Nom Heating (Gross) (6) kW
19.4 19.4 20.3 20.3 20.3
Electric Heating (Total) kW
30.0 30.0 30.0 30.0 30.0
Humidier
Capacity kg/hr
3.0 - 15.0 3.0 - 15.0 3.0 - 15.0 3.0 - 15.0 3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head m
10.8 10.8 10.8 10.8 10.8
Flow l/m
5 5 5 5 5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
1 1 N/A N/A N/A
Motor Shaft Power (4) kW
5.5 5.5 N/A N/A N/A
Speed @ Maximum ESP rpm
1695 1695 N/A N/A N/A
Maximum ESP Pa
240 240 N/A N/A N/A
Fan Power Input (Fan Gain) (2) kW
6.30 6.30 N/A N/A N/A
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2 2 2 2 2
Motor Shaft Power (4) kW
N/A N/A N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm
1935 / 2165 1935 / 2165 2165 / 2165 2165 / 2165 2165 / 2165
Maximum ESP Pa
260 260 25 25 25
Fan Power Input (Fan Gain) (2) kW
3.08 3.08 4.24 4.24 4.24
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross (7) kW
29.9 29.9 31.5 31.5 31.5
Water Flow (Nominal) l/s
0.67 0.67 0.70 0.70 0.70
LPHW Connection Sizes mm
22 22 22 22 22
