EasiCool™Precision Air Conditioning
95
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical X-TypeV
V35X - V45X2Technical Data Upow Units X Type
Electrical Data
Mechanical
(1) Entering air 24°C/45% RH ambient 35°C.
(2) Fan Gain / Fan power input based upon fan operating with design airow at 25Pa ESP, these values may change with different ESP.
(3) With Standard forward curved fan motors; Machine weight includes a refrigerant charge.
(4) Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5) For refrigerant charges, refer to Unit Refrigerant Charge (kg/Circuit).
(6) Based on air temperature of 15.5°C leaving the evaporator coil.
(7) Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to Low Pressure Hot Water.
Electrical
(1) Values given for full function units (incl. electric heating, humidication and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2) Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3) Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
V35X-EZRE-0 V35X2-EZRE-0 V40X-EZRE-0 V40X2-EZRE-0
V45X2-EZRE-0
Standard Condenser Match - X
CR50 CR50 CR65 CR65
CR80
Unit Data Full Function - X
Nominal Run Amps A
76.6 76.0 80.6 83.3
87.2
Maximum Start Amps A
220.2 140.6 217.9 172.6
169.9
Recommended Mains Fuse Size A
100 100 100 100
100
Unit Data Cooling Only - X
Nominal Run Amps A
33.3 32.7 37.3 40.0
43.9
Maximum Start Amps A
176.9 97.3 174.6 129.3
126.6
Recommended Mains Fuse Size A
40 40 50 50
50
Max Mains Incoming Cable Size mm²
35 35 35 35
35
Mains Supply V
400V / 3PH + N / 50HZ
Control Circuit VAC
24 24 24 24
24
Evaporator Fan - Motor Per Fan
Electrical Input Power kW
4.6 4.6 6.3 6.3
6.3
Full Load Amps A
8.12 8.12 10.9 10.9
10.9
Locked Rotor Amps A
60.9 60.9 69.8 69.8
69.8
Compressor - Per Compressor
Quantity x Motor Size kW
1 x 10.85 2 x 5.6 1 x 12.15 2 x 6.4
2 x 6.8
Nominal Run Amps A
19.4 9.4 20.7 11.7
12.3
Locked Rotor Amps A
163 74 158 101
95
Type of Start
Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Electrical Input Power kW
0.6 0.6 0.6 0.6
0.6
Full Load Amps A
2.62 2.62 2.62 2.62
2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
3 3 3 3
3
Number of Elements
12 12 12 12
12
Rating kW
30 30 30 30
30
Current per Phase A
43.30 43.30 43.30 43.3
43.3
Humidier
Capacity kg/hr
15 15 15 15
15
Rating kW
11.25 11.25 11.25 11.25
11.25
Full Load Amps A
16.24 16.24 16.24 16.24
16.24
Evaporator Fan Options
Larger Fan Motor - AC Motor - Per Fan
Electrical Input Power kW
6.3 6.3 N/A N/A
N/A
Full Load Amps A
10.9 10.9 N/A N/A
N/A
Locked Rotor Amps A
69.8 69.8 N/A N/A
N/A
Standard Size Motor - EC Motor - Per Fan
Electrical Input Power kW
2.55 2.55 2.55 2.55
2.55
Full Load Amps A
3.9 3.9 3.9 3.9
3.9
Condenser Fan Options
Standard Condenser Motor - EC Motor - Per Fan
Electrical Input Power kW
0.73 0.73 0.73 0.73
0.73
Full Load Amps A
3.3 3.3 3.3 3.3
3.3
