AIREDALE EasiCool - Refrigerant Pipesizing Guide - X Type Downflow

EasiCool™Precision Air Conditioning
49
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Installation
Refrigerant Pipesizing Guide - X Type Downow
Pipe lengths calculated for Indoor unit with Airedale Outdoor Unit match.
(1) For interconnecting pipework with a predominantly horizontal layout.
(2)
For interconnecting pipework with a predominantly vertical layout.
Tandem Compressor and suction throttle valve applications: In part load, gas velocity should be
taken into account when selecting and commissioning pipework to ensure full oil return.
REMEMBER excessive pressure loss in interconnecting pipework will impair system performance;
this should be factored in during the design of the system and where necessary oil separators
employed.
Indoor Outdoor
Indoor Unit Equivalent Pipe Lengths with R410A
Connection Size 0-15m 15-40m
Liquid Discharge Liquid
Discharge
Liquid
Discharge
Horizontal(1) Vertical(2) Horizontal(1) Vertical(2)
DF6X CR12
3/8” 1/2” 3/8” 1/2” 3/8” 3/8” 1/2” 3/8”
DF8X CR16
3/8” 1/2” 3/8” 1/2” 1/2” 3/8” 5/8” 1/2”
DF10X CR16
3/8” 1/2” 3/8” 5/8” 1/2” 3/8” 5/8” 1/2”
DF13X CR22
3/8” 5/8” 3/8” 5/8” 1/2” 1/2” 3/4” 5/8”
DF15X CR22
3/8” 5/8” 1/2” 5/8” 5/8” 1/2” 3/4” 5/8”
DF17X CR30
3/8” 5/8” 1/2” 3/4” 5/8” 1/2” 7/8” 5/8”
DF20X2 CR30
1/2” 7/8” 1/2” 3/4” 5/8” 1/2” 7/8” 3/4”
DF22X2 CR50
1/2” 7/8” 1/2” 3/4” 5/8” 5/8” 7/8” 3/4”
DF26X2 CR50
1/2” 7/8” 1/2” 3/4” 3/4” 5/8” 7/8” 7/8”
DF28X CR50
1/2” 7/8” 5/8” 7/8” 3/4” 5/8” 7/8” 7/8”
DF31X CR50
1/2” 7/8” 5/8” 7/8” 7/8” 5/8” 1 1/8” 7/8”
DF35X CR50
1/2” 7/8” 5/8” 7/8” 7/8” 5/8” 1 1/8” 7/8”
DF40X CR65
5/8” 1 1/8” 5/8” 1 1/8” 7/8” 3/4” 1 1/8” 7/8”
DF45X CR80
5/8” 1 1/8” 5/8” 1 1/8” 1 1/8” 3/4” 1 1/8” 1 1/8”
DF50X2 CR80
5/8” 1 3/8” 3/4” 1 1/8” 1 1/8” 3/4” 1 1/8” 1 1/8”
DF55X2 CR80
5/8” 1 3/8” 3/4” 1 1/8” 1 1/8” 3/4” 1 1/8” 1 1/8”
DF60X2 CR80
5/8” 1 3/8” 3/4” 1 1/8” 1 1/8” 7/8” 1 1/8” 1 1/8”
IMPORTANT
IMPORTANT
