AIREDALE EasiCool - V50 X2 - V60 X2

EasiCool™ Precision Air Conditioning
96
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical
X-Type V
V50X2 - V60X2Technical Data Upow Units X Type
Mechanical Data
V50X2-EZRE-0 V55X2-EZRE-0 V60X2-EZRE-0
Standard Condenser Match
1 x CR80 1 x CR80 1 x CR80
Capacity
Nom Cooling (Gross) (1) kW
50.3 56.0 62.2
Capacity Steps
2 2 2
Fan Power Input (Fan Gain) (2) kW
7.00 7.00 7.00
Dimensions - W x D x H mm
2170 x 750 x 1940 2170 x 750 x 1940 2170 x 750 x 1940
Weight - Machine (3) kg
619 636 640
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
2/1 2/1 2/1
Evaporator Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt and Pulley
Quantity
2 2 2
Motor Shaft Power (4) kW
3.0 3.0 3.0
Speed @ 25Pa / Maximum ESP rpm
1243 / 1447 1243 / 1447 1278 / 1324
Maximum ESP Pa
255 255 35
Nominal Airow m³/s
4.20 4.20 4.60
Compressor - Scroll
Tandem Tandem Tandem
Quantity
2 2 2
Oil Charge Volume (Total) l
6.60 6.60 6.60
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type (5)
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge
Inert Gas
Connections
Liquid (Sweat) in
5/8 5/8 5/8
Discharge (Sweat) in
1 3/8 1 3/8 1 3/8
Condensate Drain Hose mm
19 19 19
Filtration
Disposable to BS EN 779 - G4 - 75mm
Quantity
5 5 5
OPTIONAL EXTRAS
Larger Condenser Match
CR105 CR105 CR105
Nom Cooling (Gross) (1) kW
50.9 57.1 63.7
Hot Gas Reheat
Nom Heating (Gross) (6) kW
25.7 25.7 26.7
Electric Heating (Total) kW
30.0 30.0 30.0
Humidier
Capacity kg/hr
3.0 - 15.0 3.0 - 15.0 3.0 - 15.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head m
10.8 10.8 10.8
Flow l/m
5 5 5
Drain
10mm Stainless Steel Stub Connection
Evaporator Fan Options:
Larger Fan Motor - AC Motor
Centrifugal Forward Curved AC - Designed to 25Pa ESP
Fan Transmission Type
Belt & Pulley
Quantity
2 2 2
Motor Shaft Power (4) kW
4.0 4.0 4.0
Speed @ Maximum ESP rpm
1495 1495 1499
Maximum ESP Pa
305 305 230
Fan Power Input (Fan Gain) (2) kW
9.20 9.20 9.20
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
2 2 2
Motor Shaft Power (4) kW
N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm
1370 / 1510 1370 / 1510 1510 / 1510
Maximum ESP Pa
165 165 25
Fan Power Input (Fan Gain) (2) kW
4.18 4.18 4.18
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross (7) kW
37.7 37.7 39.2
Water Flow (Nominal) l/s
0.84 0.84 0.87
LPHW Connection Sizes mm
22 22 22
