Dimensional & Installation Data
Minimum Unit Clearances
Open & Enclosed Floorstands Option
A
B C - Floorstand(3)
Min 200 - Max 750
(+ 50mm Feet
Adjustable +/- 20mm)
D(4)
DF6 - DF10
mm 670 610 Min 300
DF13 - DF17
mm 990 610 Min 300
DF20 - DF26
mm 1310 610 Min 300
DF28 - DF31
mm 1460 700 Min 300 - Max 800
(+ 50mm Feet
Adjustable +/- 20mm)
N/A
DF35 - DF45
mm 1835 700 N/A
DF50 - DF60
mm 2170 700 N/A
Backward Curved EC Fan Motor Option
A B
C (3)
D(5)With Feet Only (4) With Leg & Feet (4)
Min Max Min Max
DF6 - DF10
mm 670 610 284 329 604 1074 Min 300
DF13 - DF17
mm 990 610 362 407 697 1152 Min 300
DF20 - DF26
mm 1310 610 362 407 697 1152 Min 300
DF28 - DF31
mm 1460 700 356 401 686 1146 Min 300
DF35 - DF45
mm 1835 700 356 401 686 1146 Min 300
DF50 - DF60
mm 2170 700 356 401 686 1146 Min 300
Minimum Ceiling Clearance
E
Forward Only
Forward & 1 Side Forward & 2 Sides All Faces
DF6 - DF10
mm 470 240 160 120
DF13 - DF17
mm 550 330 240 170
DF20 - DF26
mm 560 370 280 190
DF28 - DF31
mm 620 410 310 210
DF35 - DF45
mm 640 450 350 230
DF50 - DF60
mm 640 480 380 240
(1) Shown with optional open oor stand.
(2) Shaded area indicates minimum service and maintenance requirements.
(3) Dimension C denotes recommended minimum/maximum oorstand height, refer to Airedale for special applications, please specify at order.
(4) Min = Threaded foot at minimum extension.
Max = Threaded foot at maximum extension.
(5) Dimension D refers to units tted with LPHW which require access to the RHS of the unit to set up the regulating valve.
(6) SERVICES SIDE ACCESS GLAND PLATE, OPTIONAL POSITION; ensure appropriate clearance is available to the base of the RHS of the unit if this option is
selected.
38
