AIREDALE EasiCool - V6 X - V10 X

EasiCool™ Precision Air Conditioning
86
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical
X-Type V
Technical Data Upow Units X Type
Mechanical Data
V6X - V10X
V6X-EZRE-0 V8X-EZRE-0 V10X-EZRE-0
Standard Condenser Match
1 x CR12 1 x CR16 1 x CR16
Capacity
Nom Cooling (Gross) (1) kW
6.4 8.2 10.6
Capacity Steps
1 1 1
Fan Power Input (Fan Gain) (2) kW
0.22 0.48 0.64
Dimensions - W x D x H mm
670 x 670 x 1940 670 x 670 x 1940 670 x 670 x 1940
Weight - Machine (3) kg
174 173 177
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black, (RAL7021)
Material/Colour
Frame: Aluminium Frame with Aluminium Corners
Evaporator
Ried Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1/1 1/1 1/1
Evaporator Fan Motor - EC Motor
Centrifugal Forward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity
1 1 1
Motor Shaft Power (4) kW
N/A N/A N/A
Maximum ESP Pa
369 303 378
Nominal Airow m³/s
0.55 0.75 0.95
Compressor - Scroll
Single
Quantity
1 1 1
Oil Charge Volume (Total) l
0.70 0.70 1.20
Oil Type
Polyol Ester
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV) / R410A
Holding Charge (5)
Inert Gas
Connections
Liquid (Sweat) in
3/8 3/8 3/8
Discharge (Sweat) in
1/2 1/2 1/2
Condensate Drain Hose mm
19 19 19
Filtration
Disposable to BS EN 779 - G4 - 50mm
Quantity
1 1 1
OPTIONAL EXTRAS
Larger Condenser Match
CR16 CR22 CR22
Nom Cooling (Gross) (1) kW
6.5 8.2 10.8
Hot Gas Reheat
Nom Heating (Gross) (6) kW
4.2 4.9 5.5
Electric Heating (Total) kW
7.5 7.5 7.5
Humidier
Capacity kg/hr
0.6 - 3.0 0.6 - 3.0 0.6 - 3.0
Feed/Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Condensate Pump
Head m
8 8 8
Flow l/m
5 5 5
Drain
10mm Stainless Steel Stub Connection
Optional Fan - EC Motor
Centrifugal Backward Curved EC - Designed to 25Pa ESP
Fan Transmission Type
Direct Drive
Quantity kW
1 1 1
Motor Shaft Power (4) kW
N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm
1340 / 2215 1705 / 2215 2140 / 2215
Maximum ESP Pa
350 220 45
Fan Power Input (Fan Gain) (2) kW
0.19 0.36 0.62
Low Pressure Hot Water
Copper Tube/Aluminium Fin
Capacity Gross (7) kW
6.6 7.9 8.9
Water Flow (Nominal) l/s
0.15 0.18 0.20
LPHW Connection Sizes mm
22 22 22
Mechanical
(1) Entering air 24°C/45% RH ambient 35°C.
(2)
Fan Gain / Fan power input based upon fan operating with design airow at 25Pa ESP, these values may change with different ESP.
(3) With Standard forward curved fan motors; Machine weight includes a refrigerant charge.
(4) Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5) For refrigerant charges, refer to Unit Refrigerant Charge (kg/Circuit).
(6) Based on air temperature of 15.5°C leaving the evaporator coil.
(7) Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to Low Pressure Hot Water.
