Construction
The cabinet comprises an black painted aluminium frame with black aluminium corners and removable galvanised sheet
steel panels. The unit panels are manufactured from galvanised sheet steel coated with epoxy baked powder paint to
provide a durable nish.
Standard unit colour is Black Grey (RAL 7021). Optional Light Grey (RAL 7035)
Cabinets are lined internally with re resistant foam (UL94 V0) thermal and acoustic insulation:
• 30mm deep for removable panels
• 12mm deep for remaining internal surfaces
The cabinet doors are full height, hinged and key lock secured. Hinge arrangement allows exible door opening/removal
for improved access.
Rubberised door seals reduce sound breakout and eradicate leakage.
Simple bolt on type doors are available as a cost effective option.
Unit design incorporates a series of M6 xings to the top and bottom face for connecting to customer ductwork, please
contact Airedale for further details.
Sizes 6 - 26
Dependent upon model type, components such as the expansion valve, compressor, humidier and sight glass are
contained within an acoustically lined enclosure to provide both ease of maintenance and to minimise sound emission.
9
