Indoor Unit Standard Condenser Larger Condenser
(IR) kg/Circuit
HGRH
(OR) kg/Circuit (OR) kg/Circuitkg/Circuit
V6X-EZRE 1 1.1 CR12 1.4 CR16 2.7
V8X-EZRE 1 1.1 CR16 2.7 CR22 2.2
V10X-EZRE 1 1.1 CR16 2.7 CR22 2.2
V13X-EZRE 1.5 1.7 CR22 2.2 CR30 4.3
V15X-EZRE 1.5 1.7 CR22 2.2 CR30 4.3
V17X-EZRE 1.5 1.7 CR30 4.3 CR50 4.9
V20X2-EZRE 2.2 2.5 CR30 4.3 CR50 4.9
V22X2-EZRE 2.2 2.5 CR50 4.9 CR65 9.8
V26X2-EZRE 2.2 2.5 CR50 4.9 CR65 9.8
V28X-EZRE 2.7 3 CR50 4.9 CR65 9.8
V28X2-EZRE 2.6 2.9 CR50 4.9 CR65 9.8
V31X-EZRE 2.7 3 CR50 4.9 CR65 9.8
V31X2-EZRE 2.6 2.9 CR50 4.9 CR65 9.8
V35X-EZRE 3.3 3.7 CR50 4.9 CR65 9.8
V35X2-EZRE 3.3 3.7 CR50 4.9 CR65 9.8
V40X-EZRE 3.5 4 CR65 9.8 CR80 8.4
V40X2-EZRE 3.6 4.1 CR65 9.8 CR80 8.4
V45X2-EZRE 4.2 4.7 CR80 8.4 CR105 16.7
V50X2-EZRE 4.5 5.1 CR80 8.4 CR105 16.7
V55X2-EZRE 5.2 5.8 CR80 8.4 CR105 16.7
V60X2-EZRE 5.4 5.9 CR80 8.4 CR105 16.7
Indoor Unit Standard Condenser Larger Condenser
(IR) kg/Circuit
HGRH
(OR) kg/Circuit (OR) kg/Circuitkg/Circuit
DF6X-EZRE 1 1.1 CR12 1.4 CR16 2.7
DF8X-EZRE 1 1.1 CR16 2.7 CR22 2.2
DF10X-EZRE 1 1.1 CR16 2.7 CR22 2.2
DF13X-EZRE 1.5 1.7 CR22 2.2 CR30 4.3
DF15X-EZRE 1.5 1.7 CR22 2.2 CR30 4.3
DF17X-EZRE 1.5 1.7 CR30 4.3 CR50 4.9
DF20X2-EZRE 2.2 2.4 CR30 4.3 CR50 4.9
DF22X2-EZRE 2.2 2.4 CR50 4.9 CR65 9.8
DF26X2-EZRE 2.2 2.4 CR50 4.9 CR65 9.8
DF28X-EZRE 2.7 3 CR50 4.9 CR65 9.8
DF31X-EZRE 2.7 3 CR50 4.9 CR65 9.8
DF35X-EZRE 3.3 3.7 CR50 4.9 CR65 9.8
DF40X-EZRE 3.5 3.9 CR65 9.8 CR80 8.4
DF45X-EZRE 4.2 4.6 CR80 8.4 CR105 16.7
DF50X2-EZRE 4.5 5 CR80 8.4 CR105 16.7
DF55X2-EZRE 5.3 5.8 CR80 8.4 CR105 16.7
DF60X2-EZRE 5.4 5.9 CR80 8.4 CR105 16.7
Refrigerant Charging Guide
The following information can be used to estimate the refrigerant quantity required in a typical split system installation.
Unit Refrigerant Charge
(kg / Circuit)
The following information can be used to estimate the refrigerant quantity required in a typical split system installation.
The table shows the refrigerant charge / circuit for the indoor and outdoor units.
