EasiCool™Precision Air Conditioning
Dimensional & Installation Data
Positioning
Down ow
When placing the unit on the oorstand ensure appropriate air seal is used to prevent leakage at
the join.
It is also important to place all locking bolts in place to secure the unit to its base (EC fan
oorstands only).
Standard Return and Optional Backward Curved EC Fan Motors
Standard Return and Standard Fan Motors
CAUTION
37
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Installation
(1) With adjustable feet tted
(2) With variable size leg and adjustable feet tted
