EasiCool™Precision Air Conditioning
97
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical X-TypeV
V50X2 - V60X2Technical Data Upow Units X Type
Electrical Data
Mechanical
(1) Entering air 24°C/45% RH ambient 35°C.
(2) Fan Gain / Fan power input based upon fan operating with design airow at 25Pa ESP, these values may change with different ESP.
(3) With Standard forward curved fan motors; Machine weight includes a refrigerant charge.
(4) Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5) For refrigerant charges, refer to Unit Refrigerant Charge (kg/Circuit).
(6) Based on air temperature of 15.5°C leaving the evaporator coil.
(7) Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to Low Pressure Hot Water.
Electrical
(1) Values given for full function units (incl. electric heating, humidication and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2) Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3) Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
V50X2-EZRE-0 V55X2-EZRE-0 V60X2-EZRE-0
Standard Condenser Match - X CR80 CR80 CR80
Unit Data Full Function - X
Nominal Run Amps A 94.0 97.8 102.8
Maximum Start Amps A 235.0 210.9 246.4
Recommended Mains Fuse Size A 125 125 125
Unit Data Cooling Only - X
Nominal Run Amps A 50.7 54.5 59.5
Maximum Start Amps A 191.7 167.6 203.1
Recommended Mains Fuse Size A 63 63 80
Max Mains Incoming Cable Size mm² 50 50 50
Mains Supply V 400V / 3PH + N / 50HZ
Control Circuit VAC 24 24 24
Evaporator Fan - Motor Per Fan
Electrical Input Power kW 3.5 3.5 3.5
Full Load Amps A 6.18 6.18 6.18
Locked Rotor Amps A 43.3 43.3 43.3
Compressor - Per Compressor
Quantity x Motor Size kW 2 x 8.4 2 x 9.47 2 x 10.85
Nominal Run Amps A 15.0 16.9 19.4
Locked Rotor Amps A 156 130 163
Type of Start Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Electrical Input Power kW 0.6 0.6 0.6
Full Load Amps A 2.62 2.62 2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat 3 3 3
Number of Elements 12 12 12
Rating kW 30 30 30
Current per Phase A 43.30 43.30 43.30
Humidier
Capacity kg/hr 15 15 15
Rating kW 11.25 11.25 11.25
Full Load Amps A 16.24 16.24 16.24
Evaporator Fan Options
Larger Fan Motor - AC Motor - Per Fan
Electrical Input Power kW 4.6 4.6 4.6
Full Load Amps A 8.12 8.12 8.12
Locked Rotor Amps A 60.9 60.9 60.9
Standard Size Motor - EC Motor - Per Fan
Electrical Input Power kW 3.1 3.1 3.1
Full Load Amps A 4.8 4.8 4.8
Condenser Fan Options
Standard Condenser Motor - EC Motor - Per Fan
Electrical Input Power kW 0.73 0.73 0.73
Full Load Amps A 3.3 3.3 3.3
