EasiCool™Precision Air Conditioning
93
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical X-TypeV
V28X- V31X2Technical Data Upow Units X Type
Electrical Data
Mechanical
(1) Entering air 24°C/45% RH ambient 35°C.
(2) Fan Gain / Fan power input based upon fan operating with design airow at 25Pa ESP, these values may change with different ESP.
(3) With Standard forward curved fan motors; Machine weight includes a refrigerant charge.
(4) Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5) For refrigerant charges, refer to Unit Refrigerant Charge (kg/Circuit).
(6) Based on air temperature of 15.5°C leaving the evaporator coil.
(7) Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to Low Pressure Hot Water.
Electrical
(1) Values given for full function units (incl. electric heating, humidication and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2) Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3) Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
V28X-EZRE-0 V28X2-EZRE-0 V31X-EZRE-0 V31X2-EZRE-0
Standard Condenser Match - X
CR50 CR50 CR50 CR50
Unit Data Full Function - X
Nominal Run Amps A
59.4 58.6 63.2 63.1
Maximum Start Amps A
200.4 115.5 176.3 118.7
Recommended Mains Fuse Size A
80 80 80 80
Unit Data Cooling Only - X
Nominal Run Amps A
26.9 26.1 30.8 30.7
Maximum Start Amps A
167.9 83.0 143.9 86.3
Recommended Mains Fuse Size A
32 32 40 40
Max Mains Incoming Cable Size mm²
35 35 35 35
Mains Supply V
400V / 3PH + N / 50HZ
Control Circuit VAC
24 24 24 24
Evaporator Fan - Motor Per Fan
Electrical Input Power kW
3.5 3.5 4.6 4.6
Full Load Amps A
6.18 6.18 8.12 8.12
Locked Rotor Amps A
43.3 43.3 60.9 60.9
Compressor - Per Compressor
Quantity x Motor Size kW
1 x 8.4 2 x 4.2 1 x 9.47 2 x 4.8
Nominal Run Amps A
15.0 7.1 16.9 8.4
Locked Rotor Amps A
156 64 130 64
Type of Start
Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Electrical Input Power kW
0.6 0.6 0.6 0.6
Full Load Amps A
2.62 2.62 2.62 2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
3 3 3 3
Number of Elements
9 9 9 9
Rating kW
22.5 22.5 22.5 22.5
Current per Phase A
32.48 32.48 32.48 32.48
Humidier
Capacity kg/hr
8 8 8 8
Rating kW
6.00 6.00 6.00 6
Full Load Amps A
8.66 8.66 8.66 8.66
Evaporator Fan Options
Larger Fan Motor - AC Motor - Per Fan
Electrical Input Power kW
4.6 4.6 N/A N/A
Full Load Amps A
8.12 8.12 N/A N/A
Locked Rotor Amps A
60.9 60.9 N/A N/A
Standard Size Motor - EC Motor - Per Fan
Electrical Input Power kW
2.55 2.55 2.55 2.55
Full Load Amps A
3.9 3.9 3.9 3.9
Condenser Fan Options
Standard Condenser Motor - EC Motor - Per Fan
Electrical Input Power kW
0.73 0.73 0.73 0.73
Full Load Amps A
3.3 3.3 3.3 3.3
