EasiCool™Precision Air Conditioning
V50WX2 - V60WX2Technical Data Upow Units WX Type
Electrical Data
V50WX2-EZRE-0 V55WX2-EZRE-0 V60WX2-EZRE-0
Standard Condenser Match - X CR80 CR80 CR80
Unit Data Full Function - WX
Nominal Run Amps A 86.2 90.0 95.0
Maximum Start Amps A 227.2 203.1 238.6
Recommended Mains Fuse Size A 100 100 125
Unit Data Cooling Only - WX
Nominal Run Amps A 42.9 46.7 51.7
Maximum Start Amps A 183.9 159.8 195.3
Recommended Mains Fuse Size A 50 63 63
Max Mains Incoming Cable Size mm² 35 50 50
Mains Supply V 400V / 3PH + N / 50HZ
Control Circuit VAC 24 24 24
Evaporator Fan - Motor Per Fan
Electrical Input Power kW 3.5 3.5 3.5
Full Load Amps A 6.18 6.18 6.18
Locked Rotor Amps A 43.3 43.3 43.3
Compressor - Per Compressor
Quantity x Motor Size kW 2 x 8.4 2 x 9.47 2 x 10.85
Nominal Run Amps A 15.0 16.9 19.4
Locked Rotor Amps A 156 130 163
Type of Start Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Electrical Input Power kW 0.6 0.6 0.6
Full Load Amps A 2.62 2.62 2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat 3 3 3
Number of Elements 12 12 12
Rating kW 30 30 30
Current per Phase A 43.30 43.30 43.30
Humidier
Capacity kg/hr 15 15 15
Rating kW 11.25 11.25 11.25
Full Load Amps A 16.24 16.24 16.24
Evaporator Fan Options
Larger Fan Motor - AC Motor - Per Fan
Electrical Input Power kW 4.6 4.6 4.6
Full Load Amps A 8.12 8.12 8.12
Locked Rotor Amps A 60.9 60.9 60.9
Standard Size Motor - EC Motor - Per Fan
Electrical Input Power kW 3.1 3.1 3.1
Full Load Amps A 4.8 4.8 4.8
Condenser Fan Options
Standard Condenser Motor - EC Motor - Per Fan
Electrical Input Power kW 0.73 0.73 0.73
Full Load Amps A 3.3 3.3 3.3
133
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical WX - Type
V
Mechanical
(1) Entering air 24°C/45% RH condenser water in / out: 30°C/35°C.
(2) Fan Gain / Fan power input based upon fan operating with design airow at 25Pa ESP, these values may change with different ESP.
(3) With Standard forward curved fan motors; Machine weight includes a refrigerant charge /Operating weight includes calculated water volume.
(4) Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5) For refrigerant charges, refer to Unit Refrigerant Charge (kg/Circuit).
(6) Based on air temperature of 15.5°C leaving the evaporator coil.
(7) Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to Low Pressure Hot Water (Optional Extra) - X & WX Models.
Electrical
(1) Values given for full function units (incl. electric heating, humidication and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2) Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3) Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
