EasiCool™Precision Air Conditioning
V13WX - V17WXTechnical Data Upow Units WX Type
Electrical Data
Electrical
(1) Values given for full function units (incl. electric heating, humidication and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2) Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3) Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
V13WX-EZRE-0 V15WX-EZRE-0 V17WX-EZRE-0
Standard Condenser Match - X CR22 CR22 CR30
Unit Data Full Function - WX
Nominal Run Amps A 22.7 26.4 27.4
Maximum Start Amps A 79.6 82.0 92.0
Recommended Mains Fuse Size A 32 32 32
Unit Data Cooling Only - WX
Nominal Run Amps A 11.9 15.6 16.6
Maximum Start Amps A 68.8 71.2 81.2
Recommended Mains Fuse Size A 16 20 20
Max Mains Incoming Cable Size mm² 6 6 6
Mains Supply V 400V / 3PH + N / 50HZ
Control Circuit VAC 24 24 24
Evaporator Fan - Motor Per Fan
Electrical Input Power kW 1,1 1.6 1.6
Full Load Amps A 4.8 7.2 7.2
Locked Rotor Amps A 4.8 7.2 7.2
Compressor - Per Compressor
Quantity x Motor Size kW 1 x 4.2 1 x 4.8 1 x 5.6
Nominal Run Amps A 7.1 8.4 9.4
Locked Rotor Amps A 64 64 74
Type of Start Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Electrical Input Power kW 0.6 0.6 0.6
Full Load Amps A 2.62 2.62 2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat 1 1 1
Number of Elements 3 3 3
Rating kW 7.5 7.5 7.5
Current per Phase A 10.83 10.83 10.83
Humidier
Capacity kg/hr 3 3 3
Rating kW 2.25 2.25 2.25
Full Load Amps A 3.25 3.25 3.25
Evaporator Fan Options
Larger Fan Motor - AC Motor - Per Fan
Electrical Input Power kW N/A N/A N/A
Full Load Amps A N/A N/A N/A
Locked Rotor Amps A N/A N/A N/A
Standard Size Motor - EC Motor - Per Fan
Electrical Input Power kW 1 1 1
Full Load Amps A 1.85 1.85 1.85
Condenser Fan Options
Standard Condenser Motor - EC Motor - Per Fan
Electrical Input Power kW 0.73 0.73 0.73
Full Load Amps A 3.3 3.3 3.3
125
EasiCool Technical Manual 7525389 V1.8.0_05_2016
