EasiCool Precision Air Conditioning
0
100
200
300
400
500
600
700
800
900
2.00 2.50 3.00 3.50 4.00 4.50 5.00 5.50 6.00
Static Pressure [Pa]
AirFlow [m
3
/s]
DF50-60 Backward Fan Curve
DF 50
-
55
DF 60
1510 RPM
1250 RPM
1000 RPM
750 RPM
DF 50-60
DF50 - 60 - Backward Fan Curve
EZRE Direct Expansion 400V 50Hz (-0)
144
EasiCool Technical Manual 7525389 V1.8.0_05_2016
