EasiCool™Precision Air Conditioning
(1) Weights quoted for units tted with the standard forward curved EC fan motor include the cooling fan weight within the unit cabinet (AHU).
(2)
Machine weight includes a refrigerant charge / Operating weight includes calculated water volume..
Dimensional & Installation Data
Weights
Upow
41
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Installation
Standard Evaporator Fan - Fwd EC Motor Optional Evaporator Fan - Bkwd EC Motor
EZRE Machine
(1)
Operating
(1)
Machine
(1)
Operating
(1)
V6X kg 174 165
V8X kg 173 166
V10X kg 177 174
V13X kg 211 213
V15X kg 235 220
V17X kg 236 221
V20X2 kg 289 285
V22X2 kg 289 285
V26X2 kg 289 285
V28X kg 412 415
V28X2 kg 421 424
V31X kg 412 407
V31X2 kg 445 440
V35X kg 474 465
V35X2 kg 516 507
V40X kg 497 475
V40X2 kg 525 503
V45X2 kg 531 509
V50X2 kg 619 609
V55X2 kg 636 626
V60X2 kg 640 630
V6WX kg 189 191 180 182
V8WX kg 193 194 186 187
V10WX kg 196 197 193 194
V13WX kg 234 235 236 237
V15WX kg 265 267 250 252
V17WX kg 268 270 253 255
V20WX2 kg 326 328 322 324
V22WX2 kg 326 328 322 324
V26WX2 kg 325 328 321 324
V28WX kg 468 474 471 477
V28WX2 kg 477 483 480 486
V31WX kg 468 474 463 469
V31WX2 kg 500 506 495 501
V35WX kg 534 540 525 531
V35WX2 kg 576 582 567 573
V40WX kg 562 568 540 546
V40WX2 kg 589 595 567 573
V45WX2 kg 620 630 598 608
V50WX2 kg 709 719 699 709
V55WX2 kg 729 739 719 729
V60WX2 kg 733 743 723 733
