Technical X-TypeDF
Technical Data Downow Units X Type
Electrical Data
Electrical
(1) Values given for full function units (incl. electric heating, humidication and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2) Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3) Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
DF20X2-EZRE-0 DF22X2-EZRE-0 DF26X2-EZRE-0
Standard Condenser Match - X CR30 CR50 CR50
Unit Data Full Function - X
Nominal Run Amps A 37.7 38.1 41.1
Maximum Start Amps A 75.1 75.5 98.0
Recommended Mains Fuse Size A 50 50 50
Unit Data Cooling Only - X
Nominal Run Amps A 16.0 16.4 19.4
Maximum Start Amps A 53.4 53.8 76.3
Recommended Mains Fuse Size A 20 20 25
Max Mains Incoming Cable Size mm² 35 35 35
Mains Supply V 400V / 3PH + N / 50HZ
Control Circuit VAC 24 24 24
Evaporator Fan - Motor Per Fan
Electrical Input Power kW 1.1 1.1 1.1
Full Load Amps A 4.8 4.8 4.8
Locked Rotor Amps A 4.8 4.8 4.8
Compressor - Per Compressor
Quantity x Motor Size kW 2 x 3.3 2 x 3.3 2 x 4.2
Nominal Run Amps A 5.6 5.6 7.1
Locked Rotor Amps A 43 43 64
Type of Start Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Electrical Input Power kW 0.6 0.6 0.6
Full Load Amps A 2.62 2.62 2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat 2 2 2
Number of Elements 6 6 6
Rating kW 15 15 15
Current per Phase A 21.65 21.65 21.65
Humidier
Capacity kg/hr 3 3 3
Rating kW 2.25 2.25 2.25
Full Load Amps A 3.25 3.25 3.25
Evaporator Fan Options
Larger Fan Motor - AC Motor - Per Fan
Electrical Input Power kW N/A N/A N/A
Full Load Amps A N/A N/A N/A
Locked Rotor Amps A N/A N/A N/A
Standard Size Motor - EC Motor - Per Fan
Electrical Input Power kW 2.55 2.55 2.55
Full Load Amps A 3.9 3.9 3.9
Condenser Fan Options
Standard Condenser Motor - EC Motor - Per Fan
Electrical Input Power kW 0.73 0.73 0.73
Full Load Amps A 3.3 3.3 3.3
