EasiCool™Precision Air Conditioning
DF35X - DF45X
75
EasiCool Technical Manual 7525389 V1.8.0_05_2016
Technical X-TypeDF
Technical Data Downow Units X Type
Electrical Data
Mechanical
(1) Entering air 24°C/45% RH ambient 35°C.
(2) Fan Gain / Fan power input based upon fan operating with design airow at 25Pa ESP, these values may change with different ESP.
(3) With Standard forward curved fan motors; Machine weight includes a refrigerant charge.
(4) Backward curved EC fan options quote electrical power. All other options quote shaft power.
(5) For refrigerant charges, refer to Unit Refrigerant Charge (kg/Circuit).
(6) Based on air temperature of 15.5°C leaving the evaporator coil.
(7) Based upon low pressure hot water 82°C inlet / 71°C outlet. Air on 20°C. Refer to Low Pressure Hot Water.
Electrical
(1) Values given for full function units (incl. electric heating, humidication and matched condenser) at 7°C evaporating and 54.4°C condensing with standard
forward curved fan motors, for optional data, please contact Airedale.
(2) Values given for Cooling only units (incl. Compressor, evaporator fan and matched condenser) at 7°C evaporating and 54.4°C condensing, for optional
data, please contact Airedale.
(3) Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables.
DF35X-EZRE-0 DF40X-EZRE-0 DF45X-EZRE-0
Standard Condenser Match - X CR50 CR65 CR80
Unit Data Full Function - X
Nominal Run Amps A 65.7 69.8 78.7
Maximum Start Amps A 209.3 207.1 231.7
Recommended Mains Fuse Size A 80 80 100
Unit Data Cooling Only - X
Nominal Run Amps A 33.3 37.3 46.3
Maximum Start Amps A 176.9 174.6 199.3
Recommended Mains Fuse Size A 40 50 63
Max Mains Incoming Cable Size mm² 35 35 35
Mains Supply V 400V / 3PH + N / 50HZ
Control Circuit VAC 24 24 24
Evaporator Fan - Motor Per Fan
Electrical Input Power kW 4.6 6.3 6.3
Full Load Amps A 8.12 10.9 10.9
Locked Rotor Amps A 60.9 69.8 69.8
Compressor - Per Compressor
Quantity x Motor Size kW 1 x 10.85 1 x 12.15 1 x 13.73
Nominal Run Amps A 19.4 20.7 27.0
Locked Rotor Amps A 163 158 180
Type of Start Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Electrical Input Power kW 0.6 0.6 0.6
Full Load Amps A 2.62 2.62 2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat 3 3 3
Number of Elements 8 8 8
Rating kW 20 20 20
Current per Phase A 32.48 32.48 32.48
Humidier
Capacity kg/hr 15 15 15
Rating kW 11.25 11.25 11.25
Full Load Amps A 16.24 16.24 16.24
Evaporator Fan Options
Larger Fan Motor - AC Motor - Per Fan
Electrical Input Power kW 6.3 N/A N/A
Full Load Amps A 10.9 N/A N/A
Locked Rotor Amps A 69.8 N/A N/A
Standard Size Motor - EC Motor - Per Fan
Electrical Input Power kW 2.55 2.55 2.55
Full Load Amps A 3.9 3.9 3.9
Condenser Fan Options
Standard Condenser Motor - EC Motor - Per Fan
Electrical Input Power kW 0.73 0.73 0.73
Full Load Amps A 3.3 3.3 3.3
