68
MIXER
FX/AUX 3/4 are virtually identical to FX/AUX 1/2 except that they can also be routed to the STUDIO L and/or
STUDIO R bus. Typically, these are used to set up a foldback monitoring system for recording in a separate studio
area.
Using the mono/stereo option for the sends, you can create various different foldback configurations and you can
have the following setups:
• 1 x mono foldback mix on either AUX 3 or AUX 4.
• 2 x independent mono foldback sends each with a separate mix on each send.
• 1 x stereo foldback mix with control of level and pan for each channel allowing you to set a stereo mix in the
STUDIO outputs.
➸
NOTE :
When STUDIO L is selected, AUX 3’s output is muted. Similarly, when STUDIO R is used, AUX 4’s
output is muted.
TALKBACK
The DPS24’s internal talkback mic is permanently hardwired to the STUDIO outputs and is activated using the
TALKBACK button located above the MASTER fader.
➸
NOTE :
The talkback mic only appears at the STUDIO L and/or R outputs are used/enabled in the FX/AUX
SETUP page. The talkback mic will not be heard through the STUDIO outputs if busses 3 and/or 4 are routed
to the internal effects or the AUX bus.
