SETUP

SETUP MODE

The SETUP page allows you to set certain functions that affect the DPS24 as a whole. Pressing SETUP shows this

page:

Here, you can set the following functions using Q1-Q6:

SAMPLE RATE Here, you can set the sample rate for the DPS24. The options are 32kHz, 44.1kHz,

48kHz and 96kHz.

➸

NOTE :

Selecting a sample rate other than that of the currently loaded project will cause previously re-

corded material to playback at the wrong speed. It is recommended, therefore, that you do not change the

‘system’ sample rate after loading a project or after recording into a new project.

DIGITAL SYNC Selects the wordclock source. The options are:

INTERNAL The DPS24 will sync to its own internal clock

WCLK The DPS24 will sync to a sync source connected to the Wordclock

BNC connector on the rear of the DPS24.

SPDIF The DPS24 will sync to a digital audio source connected to the co-

axial digital input on the rear of the DPS24.

ADAT 1-8 The DPS24 will sync to a digital audio source connected to the

optical digital input on the rear of the DPS24.

External wordclock should match the sampling rate set for the current project.

➸

NOTE :

If the selected digital sync source is not available, you will receive a prompt informing you. Also,

to prevent unwanted noise, all audio is automatically muted and the top of the LCD will show:

Certain operations will also be unavailable to you on the DPS24.

To remedy this situation, you should either select INTERNAL or you should attend to the digital sync source’s

problem.
