Akuvox R26 Series - Static IP Mode; Local RTP

R26/R23 Series
Admin Guide
8
R26/R23X uses DHCP by default, and it will obtain IP address,
subnet mask, default gateway and DNS server address from DHCP
server automatically.
3.3.2.2. Static IP Mode
Go to Network - Basic to configure.
If selected, users could manually set IP address, subnet mask,
default gateway and DNS server. The figure below shows static IP
setting.
3.3.2.3. Local RTP
Go to Network - Advanced to configure. To display and configure
Local RTP settings.
Max RTP Port: Determine the maximum port that RTP stream can
use.
Figure 3.3.2.3 Local RTP
Figure 3.3.2.2 Static IP mode
