R26/R23 Series
Admin Guide
Display Name: To configure name sent to the other call party for
displaying.
Register Name: To enter extension number you want and the
number is allocated by SIP server.
User Name: To enter user name of the extension.
Password: To enter password for the extension.
3.4.2.2. SIP Server 1&2
Server IP 1: To enter SIP server’s IP address or URL.
Server IP 2: To display and configure secondary SIP server settings.
This is for redundancy, if registering to primary SIP server fails, the
phone will go to secondary SIP server for registering.
Registration Period: The registration will expire after registration
period, the phone will re-register automatically within registration
period.
Figure 3.4.2.2-1 SIP server 1&2
Figure 3.4.2.2-2 SIP server 1&2
