R26/R23 Series
Admin Guide
34
Go to Phone - WebRelay to configure.
Type: Connect web relay and choose the type.
IP Address: Enter web relay’s IP address.
UserName: It is an authentication for connecting web relay.
Password: It is an authentication for connecting web relay.
Web Relay Action: Web relay action is used to trigger the web relay.
The action URL is provided by web relay vendor.
Web Relay Key: If the DTMF keys same as the local relay, the web
relay will be open with local relay. But if there are different, the web
relay is invalid.
Web Relay Extension: The webrelay can only receive the DTMF
signal from the corresponding extension number.
Note: Users can modify username and password in web relay
website.
Figure 4.3.1-2 Web relay
