HP106 Service Manual
Page 3 of 12
1 TECHNICAL SPECIFICATIONS
1.1 Test methods
ETS 300-086
IEC 529 IP54 and MIL STD 810 C/D/E
1.2 Specifications table
General
Characteristic Units Value/Measurements conditions
Frequency MHz from 148 to 174
Operating Band MHz 26
Number of Programmable Channels - 16
Channel Spacing KHz 12.5 / 20 / 25
Frequency Steps KHz 5 / 6.25
Rated Power Supply Vcc 7.5
Battery Capacity mAh Ni-MH 1.300
5% on TX at the maximum power
5% on RX at 60 % of the maximum rated A.F. power
Duty Cycle hours
90% on RX with closed squelch in power save mode
8
Antenna Impedance Ohm 50
Speaker Impedance Ohm 8
Frequency Stability ppm
±2.5
Operating Temperature Range °C from –30 to +60
Transmitter
Output Power (±1 dB)
W 1 / 5
from 9 KHz to 1 GHz
< 0,25 Spurious Emissions
µW
from 1 to 4 GHz
< 1
Modulation System - F3E (FM)
Modulation KHz
± 2,5 / 5
Audio Distortion - 5 % or less
Maximum Deviation KHz
± 2.5 / 5
Adjacent Channel Power Attenuation dB < -60 / -70
Receiver
Configuration Double Conversion Superetherodyne
Sensitivity (at 12 dB SINAD)
µV
< 0.35
Squelch Sensitivity (SINAD) dB 10
Selectivity (Adjacent Channel) dB At least -65 / -75
Spurious Response Rejection dB > 70
Intermodulation dB > 65
Hum & Noise Suppression dB < -45 / < -40
Audio Output (1 KHz at 5% T.H.D.) mW 400
Mechanical Specifications
Size (Battery Pack Included) mm 130 x 42 x 60
Weight (Battery Pack Included) g 355
Battery - Back slide battery
Accessories Connector / Programming - 2.5 and 3.5 mm standard monophonic jacks
Moisture & Dust Resistance - According to the IEC529 and IP54 regulations
