4.2 Structure of Global Data window
As you can see, Global Data window is divided into three areas: Set-Up, Set-Up 2 and Tables
Set-Up Set-Up 2 Tables
The Set-Up area allows you to
adjust or enable/disable various
radio’s parameters, such as the
scan configuration, the TX timeout
and PTT lock condition, set up the
acoustic signals, switch the
scrambler on/off and many other
customizations. For further
information please see the Chapter
6
The Set-Up 2 area is useful to set
up additional parameters, such as
the emergency call and the power
save ones. For further information
please see the paragraphs 6.9 and
6.10
The Tables area allows you to
define the parameters for the
Selective Calls and setup RX and
TX tone sequences. For further
information please see the Chapter
5
Moreover, there are two buttons at the window’s bottom:
 The Channels data button, which allows to quickly recall the Channel data window as described in the par. 4.1
 The Channel Data Summary button, which allows to quickly see a channel data summary which includes the main parameters of all
the programmed channels. For further information please see the par. 5.7
