HP-106/406 EXPLODED VIEW PART'S LIST.
NO. PART NO. PART NAME DESCRIPTION Q'TY Remark codice cte
1 719-896 Cov Front PC 1
2 795-920 Name Plate PC Clear T0.3 1
3 719-894 Cov Spk/Mic ABS 1
4 895-789 PTT Button Silicone Rubber 1
5 733-005A Holder PTT PC 1
6 853-223 Ring GND BSBM CR Plate 1
7 753-127 Spacer Ant Acetel CR-Plate 1
8 650-358 Nut Ant M8x0.75 BSBM CR-Plat 1
9 420-420-2 Ant NSB97-H100-CI2 1 420-420-0 ( HP-405)
10 895-787 Gasket (Vol ) Silicone Rubber 1
10-1 895-788 Gasket Ch Silicone Rubber 1
11 907-023 Sheet Tapping PE T0.15 1
12 702-483 Top Panel ABS 1
13 881-672 Spring "D" Volum SK5 T0.2 1
13-1 881-609A Spring Ch BECU T0.2 1
14 826-450 Knob Vol ABS 1
14-1 826-449 Knob Ch ABS 1
15 895-793 Lens LED Silicone Rubber 1
16 907-020 Felt (Speaker) FELT T0.3 1
17 420-127-6 Speaker 40-8BB-24F 1
18 600-814 Screw (PH) M2x5 Blk (H=T1.1) 2
19 632-006 Screw (BH) BLK T2.4 1
20 772-516 Shield can C SPTE TO.3 1
21 772-514 Shield can A SPTE TO.3 1
22 772-515 Shield can B SPTE TO.3 1
23
30-068 5A SW Rotary Code EC10SP16-31 1
24 772-517 Shield can D SPTE TO.3 1 For HP-405 only
25 611-391 Screw M2.6x10 (+) BH Ni-Plat 2
26 650-357 Nut ( Volume) For Ch M7x0.75 BSBM Ni-plate 1
27 632-005 Tapping Screw (+) PH Ni-Plate T2x5 9
28 480-064-6 Potentiometer 10K MVR22 HX BR N13 1
29 420-8501 Jack HSJ1468-01-030 1
30 416-128-B Main PCB FR4 2/S 1
31 895-786 Bushing Mic Silicone Rubber 1
32 895-791 Gasket SP/MIC Jack Silicone Rubber 1
33 753-125 Terminal Gnd NSS To.2 1
34 853-225 Insulator Ant PC CR Plate 1
35 753-126 Terminal Ant NSS To.2 1
36 853-224 Connector Ant BSBM CR Plate 1
37 611-392 Screw M2.6x6 (+) BH SUS BLK 1
38 719-895 Cover Ant Flxer PC 1
