Alcatel-Lucent 7210 SAS M Interface Configuration Guide

LAG Commands
Page 320 7210 SAS M, T, X, R6, R12, Mxp Interface Configuration
Guide
LAG Associations Output — The following table describes LAG associations output fields.
Sample Output
A:ALA-1# show lag 5 associations
==============================================================================
Interface Table
==============================================================================
Router/ServiceId Name Encap Val
------------------------------------------------------------------------------
Router: Base LAG2West 0
------------------------------------------------------------------------------
Interfaces
==============================================================================
A:ALA-1#
LAG Details — The following example displays LAG output
*A:dut-c# show lag 2 detail
===============================================================================
LAG Details
-------------------------------------------------------------------------------
Details
-------------------------------------------------------------------------------
Lag-id : 2 Mode : network
Adm : up Opr : up
Thres. Exceeded Cnt : 85 Port Threshold : 0
Thres. Last Cleared : 05/17/2009 07:56:24 Threshold Action : down
Dynamic Cost : false Encap Type : null
Configured Address : 00:ab:00:5a:01:1d Lag-IfIndex : 1342177282
Hardware Address : 00:ab:00:5a:01:1d
LACP : enabled Mode : active
LACP Transmit Intvl : fast LACP xmit stdby : enabled
Selection Criteria : highest-count Slave-to-partner : disabled
Number of sub-groups: 1 Forced : -
System Id : 00:ab:00:5a:01:01 System Priority : 32768
Admin Key : 32769 Oper Key : 32769
Prtr System Id : 00:9a:9a:ba:ba:60 Prtr System Priority : 32768
Prtr Oper Key : 32769
-------------------------------------------------------------------------------
Port-id Adm Act/Stdby Opr Primary Sub-group Forced Prio
-------------------------------------------------------------------------------
1/1/5 up active up yes 1 - 32768
1/1/6 up active up 1 - 32768
-------------------------------------------------------------------------------
Port-id Role Exp Def Dist Col Syn Aggr Timeout Activity
Label Description
Service ID
The service associated with the LAG.
Name The name of the IP interface.
Encap Val The values of the port for the IP interface.
