Card, Adapter Card, and Port Command Reference
Page 200 7705 SAR OS Interface Configuration Guide
Table 33: Show Multilink Bundle IMA Group Detailed Output Fields
Label Description
Description Displays the configured description for this bundle
Bundle Id The port ID for this bundle
Admin Status Up — the bundle is administratively up
Down — the bundle is administratively down
Minimum Links The minimum number of links that must be active for a bundle to be
active. If the number of links drop below the given minimum, then the
multilink bundle will transition to an operation down state.
Total Links The total number of active member links configured for this bundle
Red Diff Delay The maximum acceptable differential delay for individual circuits
within this multilink bundle. If the delay exceeds this threshold, a trap
is issued.
Red Diff Delay
Act
The action that will be taken on the IMA group once the Red Diff
Delay is exceeded
Oper MTU The negotiated size of the largest packet that can be sent on the port or
channel, specified in octets
Mode network — the port is configured for transport network use
access — the port is configured for service access
Type Indicates that this bundle is of type IMA group
Oper Status The operational port status of a member link
Bundle IfIndex Displays the bundle’s interface index number, which reflects its
initialization sequence
Active Links The total number of active links for the bundle
Bandwidth The bandwidth configured for this IMA group bundle in kb/s
Traffic and Port
statistics
The traffic and port statistics information displayed for bundles when
the detail option is selected is the same as information displayed for
physical ports
