Card, Adapter Card, and Port Command Reference
Page 82 7705 SAR OS Interface Configuration Guide
Card Commands
card
Syntax card slot-number
no card slot-number
Context config
Description This mandatory command is the first step in activating the IOM software: designating it a slot
position in the chassis. On the 7705 SAR, the slot number is always 1.
The IOM software must be activated before the adapter cards and ports can be configured.
The no form of this command removes the card from the configuration. All associated ports, services,
and adapter cards must be shut down.
Default None
Parameters slot-number — the slot number of the card in the chassis
Values 1
card-type
Syntax card-type card-type
no card-type
Context config>card
Description This mandatory command is the second step in activating the IOM software: designating the card
type. The card type can be preprovisioned, meaning that the card does not need to be installed in the
chassis. On the 7705 SAR, the card type is always iom-1g.
A card must be provisioned (configured) before an adapter card or port can be configured.
A card can only be provisioned in a slot that is vacant, which means that no other card can be
provisioned for that particular slot. To reconfigure a slot position, use the no form of this command to
remove the current information. Port and adapter card information must be shut down.
A card can only be provisioned in a slot if the card type is allowed in the slot. An error message is
generated if an attempt is made to provision a card type that is not allowed.
The no form of this command removes the card from the configuration. This operation requires that
the card be administratively shut down. All dependencies to ports on this card must be shut down and
removed from the configuration before issuing the no card-type command.
Default None
