Alcatel-Lucent 9130 BSC Evolution - LIU Front Filler Replacement

4 Maintain the LIU Subrack
4.5 Replace LIU Front Filler
The following figure shows the JBXDUM filler.
JBXDUM
Figure 26: JBXDUM Filler
4.5.1 Remove JBXDUM
To remove JBXDUM filler:
1. Unfasten the top screw with the screwdriver.
2. Unfasten the bottom screw with the screwdriver.
3. Remove the JBXDUM filler.
4.5.2 Replace JBXDUM
To replace JBXDUM filler:
1. Fit the filler into position.
2. Fasten the top screw with the screwdriver.
3. Fasten the bottom screw with the screwdriver.
