6 Software Procedures
6.3.2 Modify BSC IP Subnetwork Address
To modify IP subnets address with BSC terminal:
1. Open the BSC terminal
From the Windows desktop, click on Start -> Programs -> WinBSC -> 9130
BSC –> B10 –> Windows 9130 BSC BSC Terminal B10, and enter
the Virtual IP address of the BSC.
The Virtual IP address is 172.17.33.1
2. Switch to master user mode.
3. From the BSC Terminal menu bar, follow the menu path:
Commands -> BSS Operations -> Dis Declare BSC Peer Entities
The "Display Dec BSC Peer Entities" window opens.
4. Complete the following fields:
In ’Object Class’, select BSC
In ’Unit Type’, select BSC
In ’Unit Number’, enter 1.
5. Select the ’Get and Modify’ option.
6. Click on [ OK ].
The "Declare BSC Peer Entities" window opens.
7. Click on the Address - 2 tab and complete the fields as follows:
In the ’BSC IP SUB NET B:’, type the new IP subnet address
In the ’BSC IP B MASK’, type the new IP subnet B mask address
of the BSC
In the ’BSC IP SUB NET C:’, type the new IP subnet C address of
the BSC
In the ’BSC IP C MASK’, type the new IP subnet C mask address
of the BSC
In the ’IP MLPP:’, type the new IP MLPP (IP bandwidth) of the BSC.
The ’IP MLPP:’ parameter is used only for TC and MSC extraction
mode configuration.
8. Click on the Address - 3 tab and complete the fields as follows:
In the ’EXTERNAL ROUTER SUBNET B’, type the new IP address for
External Router interface connected to Subnet B.
In the ’EXTERNAL ROUTER SUBNET C’, type the new IP address for
External Router interface connected to Subnet C.
9. Click on [ OK ] to save the changes.
Wait for a DECLARE BSC PEER ENTITIES successful message in the
"Compressed Report View" window.
10. Close BSC terminal.
84 / 90
3BK 21281 AAAA PCZZA Ed.13
