Alcatel-Lucent 9130 BSC Evolution - ATCA Subrack Cables

5 9130 BSC Evolution Cables
The following table gives the boards position in the ATCA shelf and part
numbers.
Description of the
platform Position
Alcatel-Lucent part numbers
Shelf (chassis) 1AF 04442 AD
Board M07 & M08 3BK 27237 AASwitches
ARTM M67 & M68 1AF 04448 AA
Board M06 & M09 1AF 04452 ACJBXOMCP boards
ARTM M66 & M69 1AF 04451 AA
JBXCCP boards Board M64 - M65 &
M70 - M71
3BK 27231 AA
JBXTP Board M01 & M02 3BK 26859 AA
Table 5: ATCA Configuration
5.2 ATCA Subrack Cables
Cable Mnemo
Item
Reference
Cord
From (device,
connector)
To (device,
connector)
blue (-48V) AB, M83/P01 Z (A), P11JL16H2M6 (CJ)
blue-black (0V) AB, M83/P02 Z (A), P21
blue (-48V) AB, M82/P01 Z (B), P15JL16H2M6 (CJ)
blue-black (0V) AB, M82/P02 Z (B), P25
blue (-48V) AB, M81/P01 Z (A), P12JL16H2M6 (CJ)
blue-black (0V) AB, M81/P02 Z (A), P22
74 / 90 3BK 21281 AAAA PCZZA Ed.13
