109ALI-DVR3000H Series 960H DVR User Manual
SECTION 11
Specications
Section Item ALI-DVR3004H ALI-DVR3008H ALI-DVR3016H
Video/Audio Input Video Compression H.264
Video Input 4 channels 8 channels 16 channels
Video Input Interface BNC (1.0 Vp-p, 75 Ω)
Audio Compression G.711u
Audio Input 1 channel, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio input 1 channel, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio Output CVBS Output 1 channel, BNC (1.0 Vp-p, 75 Ω), resolution: 704 × 480
HDMI / VGA Output 1 channel, resolution: 1920 × 1080 × 60Hz , SXGA: 1280 × 1024 × 60Hz.
1280 × 720 × 60Hz , 1024 × 768 × 60Hz
Video Loop Out 4 channels, BNC (1.0 Vp-p, 75 Ω)
Frame Rate 960H / 4CIF / 2CIF @ /15 fps;
CIF / QCIF @ 30 fps
960H @ 8 fps;
4CIF / 2CIF @ 10 fps;
CIF / QCIF @ 30 fps
Synchronous Playback 4 channels 8 channels 16 channels
Video Bit Rate 32 kbps ~ 3072 kbps, or user dened (max. 3072 kbps)
Stream Type Video / Video & audio
Audio Output 1 channel RCA (linear, 1 kΩ)
Audio Bit Rate 64 kbps
Dual Stream Supported; sub-stream: CIF / QCIF @ 30 fps
Encoding resolution WD1 / 4CIF / 2CIF / CIF / QCIF
Hard Disk Capacity Up to 4TB
SATA 1 SATA interface
External Interface Network Interface 1, RJ-45 10M/100M adaptive Ethernet
USB Interface 2, USB 2.0
Serial Interface 1, RS-485 interface, half-duple 1, RS-485 interface, half-duplex
General Power supply 12 Vdc
Consumption < 10 W < 10 W < 15 W
Working temperature 14°F ~ 131 °F (-10 °C ~ +55 °C)
Working humidity 10 % ~ 90 %
Chassis Standalone 1U chassis
Dimension (w × d × h) 12.4" × 9.1" × 1.8" (315 mm × 230 mm × 45 mm)
Weight ≤ 4.4 lb (≤ 2 kg) w/o hard disk and DVD-R/W
