3ALI-DVR3000H Series 960H DVR User Manual
SECTION 1: SYSTEM OVERVIEW
• TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, UPnP™, RTSP, iSCSI are supported.
• TCP, UDP and RTP for unicast.
• Remote search, playback, download, locking and unlocking the record les, and downloading les broken transfer resume.
• Remote parameters setup; remote import/export of device parameters.
• Remote viewing of the device status, system logs and alarm status.
• Remote locking and unlocking of control panel and mouse.
• Remote HDD formatting and program upgrading.
• Remote system restart.
• Alarm event and exception information can be sent to the remote host.
• Remotely start/stop recording.
• Upgrade by remote FTP server.
• Two-way audio and voice broadcasting.
• Embedded WEB server.
1.1 DVR Controls, connectors and indicators
Your new security system is easy to use and easy to setup. This section includes the function and use of the components included
with a DVR system. For installation instructions, refer to Section 2. Advanced control and conguration procedures are included in
Sections 3 through 9.
DVR Front Panel
USB Interface
IR ReceiverPower LED
Status TX / RX
ALI-DVR3000H series front panel
Item Usage
Power LED Indicator turns green when DVR is powered up.
Status STATUS indicator lights in red when HDD is reading/writing.
TX / RX LED indicator blinks green when network connection is functioning properly.
IR Receiver Sensor for the remote control.
USB Interface This port can be used for a USB mouse or USB ash memory devices.
