5ALI-DVR3000H Series 960H DVR User Manual

SECTION 1: SYSTEM OVERVIEW

Item Description

11 12 Vdc Plug for 12 Vdc power adapter.

12 GND terminal Ground terminal post.

1.1.1 Remote control

The enter key on the remote control or the front panel has the same function as a mouse left click. The IR Range of the remote

control is 10 meters. The buttons on the remote control correspond with the buttons on the front panel.

7 5

6 4

11141518 16

1213 10

Item Name Function

1 POWER Power on/o the device.

2 DEV Enables/Disables Remote Control.

3 Alphanumeric Buttons Switching to the corresponding channel in Live view or PTZ Control mode.

Inputting numbers and characters in Edit mode.

Switching between dierent channels in All-day Playback mode.

4 EDIT Button Editing text elds. When editing text elds, it will also function as a Backspace button to delete the charac-

ter in front of the cursor. On checkbox elds, pressing the EDIT button will tick the checkbox.

In Playback mode, it can be used to generate video clips for backup.

5 A Button Switching between input methods (upper and lowercase alphabet, symbols and numeric input).

6 REC Button Entering the Manual Record settings menu.

In PTZ control settings, press the REC button and then you can call a PTZ preset by pressing Numeric button.

7 PLAY Button Playback, for direct access to playback interface.

8 INFO Button Reserved.

9 VOIP button Selecting all items on the list;

In live view or playback mode, it can be used to switch between main and spot video output

10 MENU button Press the button will help you return to the Main menu (after successful login).

Press and hold the button for 5 seconds to turn o audible key beep.

11 PREV button Switch between single screen and multi-screen mode.
