32
SECTION 4
Live View Interface
The Live View interface is the primary camera viewing and monitoring mode. It can be congured to present video from the
cameras congured in the system singularly or in multi mode, or using a “patrol” feature wherein video from each of a select group
of cameras is displayed singularly and sequentially, with each camera view shown for a preset duration (dwell). The Live View
screen can be congured to display 1, 6 or 8 camera channels concurrently, or playback recorded video.
Live View 2 * 2 multi-screen display
Each camera channel displayed on the Live View screen may contain one or both status icons in the upper-right corner of the
viewing frame.
Live View Status icons
Icon Type Reason
Alarm Video loss, tampering, motion detection or sensor alarm
Record Manual record, schedule record, motion detection or alarm triggered record
SECTION 4: LIVE VIEW INTERFACE
