CHAPTER 4 ALIEN READER PROTOCOL
READER INTERFACE GUIDE
DOC. CONTROL # 8101938-000 REV 05
33
A
UTONOMOUS MODE COMMANDS
Command Description
9800
9780
8780
9640
9770
get AutoMode
set AutoMode
Switch auto mode on and off.
✔✔✔✔✔
get AutoWaitOutput
set AutoWaitOutput
Specify the value of the output pins while in wait mode.
✔✔✔✔
get AutoStartTrigger
set AutoStartTrigger
Get and Set the trigger that sends the auto mode state
into working state.
✔✔✔✔
get AutoStartPause
set AutoStartPause
Get and Set the time to wait after receiving a start
trigger before starting AutoMode
✔
get AutoWorkOutput
set AutoWorkOutput
Specify the value of the output pins while in work mode.
✔✔✔✔
get AutoAction
set AutoAction
Get and Set the action to perform in auto mode.
✔✔✔✔
get AutoStopTrigger
set AutoStopTrigger
Set and Get the external trigger that will move the auto
mode state from work mode to evaluate mode.
✔✔✔✔
get AutoStopTimer
set AutoStopTimer
Set and Get the timer that will move the auto mode
state from work mode to evaluate mode.
✔✔✔✔
*
get AutoTrueOutput
set AutoTrueOutput
Specify the value of the output pins when the auto
mode evaluation returns a True condition.
✔✔✔✔
get AutoTruePause
set AutoTruePause
Set and Get the pause time after the auto mode
evaluation returns a True condition.
✔✔✔✔
get AutoFalseOutput
set AutoFalseOutput
Specify the value of the output pins when the auto
mode evaluation returns a False condition.
✔✔✔✔
get AutoFalsePause
set AutoFalsePause
Set and Get the pause time after the auto mode
evaluation returns a False condition.
✔✔✔✔
AutoModeTriggerNow Force a trigger event to occur.
✔✔✔✔
AutoModeReset Reset all auto mode values to their default states.
✔✔✔✔✔
get AutoModeStatus Get the current status of auto mode.
✔✔✔
* The ALR-9770 also uses the AutoStopTimer value as a time limit on individual
read operations. See the AutoStopTimer discussion on the following pages for
more information.
