184 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 4 Measurement Definition
Module Definition – Input Data
On the Input Data page, in the Channel Pairs section, select Differential
Expansion for the channel pair to be used. Also, for each channel of the pair,
select the Bias/Gap data input as a way of verifying gap settings during initial
setup of the probes on the machine.
Figure 79 - Input Data
No other selections are necessary in Module Definition for the Ramp
Differential Expansion measurement. Configure the other channels, inputs,
outputs, and add expansion modules as appropriate.
