Allen-Bradley 1444-TSCX02-02RB User Manual

52 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 2 Install the Dynamix 1444 Series Monitoring System
Wiring the Power
Figure 9 connects positive and negative power to the first (from left) of two
identical connectors for each. See Main Module Connectors
on page 51 for the
list of power connections.
Figure 9 - Typical Wiring for Single and Redundant Power Solutions
Supply 0
24VDC
Power
Supply
Supply 1
24VDC
Power
Supply
56
54
52 50
