Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 199
Configure and Replace Safety Modules Chapter 7
Table 46 describes the parameters that are available on the Module Definition
dialog box.
Table 46 - Module Definition Parameters
Parameter Definition Available Choices
Series Module hardware series Module-specific
Revision Module firmware revision, including major and minor revision levels Module-specific
Electronic Keying Software method by which you reduce the possibility of using the wrong device in a control system.
For more information, see the following:
•
Electronic Keying on page 74
• Electronic Keying in Logix5000 Control Systems Application Technique, publication
LOGIX-AT001
• Exact Match
• Compatible Module
• Disable Keying
We strongly recommend
that you use Exact Match or
Compatible Module in Safety
applications.
Configured By Determines the following for the module type you configure:
• Which controller tags are generated when configuration is complete
• Whether you can choose an Output Data type - Output module only
• Whether you can choose an Output Mode - Output module only
• Whether muting lamp points can be used - Input module only
• This Controller
• External Means
(1)
Input Data Determines what type of input data is exchanged between the module and the controller.
Creates all controller tags specific to the module type being used.
IMPORTANT: The 5069-OBV8S and 5069-OBV8SK output modules exchange input data with the controller.
• Safety data
• Safety packed data
Muting Lamp Points - 5069-IB8S
or 5069-IB8SK module only
Determines which input channels, if any, are connected to muting lamps. • None
• Point 02
• Point 03
• Point 02 and 03
Output Data - 5069-OBV8S or
5069-OBV8SK module only
Determines what type of output data is exchanged between the module and the controller.
The available choices are dictated by the Configured By parameter choice.
• None - If Configured By is
External Means.
• Safety data and Safety
packed data - If
Configured By is This
Controller.
Output Mode - 5069-OBV8S or
5069-OBV8SK module only
Determines how the outputs are used. That is, one of the following:
• Sourcing outputs. In this case, you connect the external device to only the sourcing point on an output
channel.
• As connection pairs. In this case, you connect the external device to both the sourcing and sinking points
on an output channel.
• Sourcing
• Bipolar
(1) Controller and module establish communication without the controller sending any configuration or output data to the module. A full input data connection is established but depends on the
connection between the owner-controller and the module.
