42 Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Chapter 1 Digital Module Operation in a Control System
Table 8 describes the connection types that you can use with Compact 5000
I/O standard modules.
Table 8 - Connections - Compact 5000 I/O Standard Modules
Connection Type
Description
Compact 5000 I/O Standard Input Modules Compact 5000 I/O Standard Output Modules
Data The module returns the following to the owner-controller:
• General input data
• General fault data
• Counter data - Not available with all modules
The module returns the following to the owner-controller:
• General fault data
• Output data
Data with Events
(1)
The module returns the following to the owner-controller:
• General input data
• General fault data
• Input data time stamp
• Event input data time stamp
• Event fault data
• Event input data
• Event output data
• Counter data - Not available with all modules. With the modules that
can provide counter data, they only provide it based on the Input Data
selection.
—
Listen Only Data A controller can make a Listen Only Data connection with only some standard local I/O modules. When a Listen Only data connection is used, another
controller owns the module.
A controller that makes a Listen Only Data connection to the module does not write configuration for the module. It merely listens to the data
exchanged with the owner-controller. That is, the listening controller listens to general input data and general fault data.
IMPORTANT: If a controller uses a Listen Only connection, the connection must use the Multicast option.
For more information on Listen Only connections, see
Listen Only on page 56. In this case, all other connections to the module, for example, the
connection to the owner-controller must also use the Multicast option.
(1) Data with events is available on only the 5069-IB16F and 5069-IB6F-3W standard input modules.
