Allen-Bradley DeviceNet 1756-DNB User Manual

3–21Configuring Through DeviceNet Manager Software
Publication 1756–6.5.15 – July 1998
When you save Module Configuration or Scan List Editor
information to a file, each is given a specific extension.
• MCC data is stored in .sm5 files
• Scan list data is stored in .sl5 files
• Scan list reports are stored in .lr5 files
• Scan list map reports are stored in .mr5 files
• Custom launch data is stored in .clc files
When you access the communication module configuration screens
from Project View, communication module files are stored at the
project level.
When you access the communication module configuration screens
from Network Who, you choose where to store the communication
module files. This is because there is no project data attached to
Network Who.
If you feel ready to proceed with your configuration process, apply
to your system the procedures discussed in chapters 2 and 3. If you
need further information, continue on to the scan list file example in
appendix B.
• Photoelectric sensor scan list example
• RediSTATION operator interface scan list example
If You Encounter Error Messages
If you encounter error messages while building your scan list file,
refer to the troubleshooting table in appendix A.
• Input maps 1-4 errors
• Input message-type errors
• Output maps 1-4 errors
• Output message-type errors
• Mapping and/or auto map errors
About
Y
our
F
il
es
What’
s
N
ex
t
?
